Infill G4 Double-DIN Car-PC Barebone (1.5Ghz, FM radio, Amplifier, GPS)

BACK : VIA ITX MiniPCs

CPU	VIA C7 1.5Ghz	RAM	1x SO-DDR-II
Graphic	VIA UniChrome PRO II	Audio	AC97 Codec
Formfactor	Double DIN	Base

USB	3x USB 2.0	LAN	--
Firewire	--	Parallel	--
IDE/SATA	1x Slim-IDE, 1x SATA	Serial	--

TV-Out		Passive cooling
PCI		PCI-Express
Mini-PCI		PCMCIA
IDE		SATA
DVI		CPU changeable
800x480 Resolution		Compact_Flash

CURRENTLY NOT AVAILABLE!

Car-PC Barebone : Choose yourself : RAM, HDD, Slimline SlotIn drive

Fast Boot : 3 Seconds boot time into Windows !

Battery protection : The device turns off power completely after 18 hours of inactivity (deep discharge protection).

Dualview : Dualview possible via the additional VGA output.

Attention : Please only use Panasonic or Quanta Slot-In drives because of the location of the eject button !

CPU	VIA C7 1.5GHz
Chipset	VIA CX700M
Grafik	VIA UniChrome™ Pro II IGP (Built in HDTV Encoder with Macrovision® support) Hardware Acceleration for MPEG-2, MPEG-4, WMV9
Memory	1x SO-DDR2 256-1024 MB RAM(not included)
LCD	800 X 480 6.5" TFT LCD SHARP (500 nits)
TOUCH	6.5" Touch Screen
Audio	HD Audio CODEC
USB	Front 1 port / Rear 2 port
HDD	1x 2.5" SATA HDD (not included)
DVD-ROM	1x Slimline CD/DVD Slot-In (not included)
RADIO	FM section:87.5~108 MHz / AM section:153~1710 KHz
AMP	44Wx4CH / 5.1CH Preout 3V rms
GPS	Internal GPS Module (Sirf3 chipset) with external aerial
Video	1x Rear camera-input (NTSC), 1x VGA output
S/W	Infillstation Touchscreen Desktop Interface
Compability	WinXP (recommended), Win9x/ME, NT, DOS, Linux,...
Dimensions	178mm (W) x 100mm (H) x 193mm (D) [plus 32mm Overlap Front]
Scope of Supply	- Infill G4 Car-PC Barebone - IR Remote - Touchscreen-pencil (Touchscreen can also be used with fingers) - GPS-aerial - Video-Adapter-connector cable - USB-Adapter-connector cable - Power/Speakers/Misc-connector cable - DriverCD - Infill CarPC Touchscreen Desktop Software

Installation Tutorial : Support / Manuals



Note : Self-Assemblng only recommended for advanced users. We can assemble your system very fast ! Please order through the systembuilder then and select "Assembling" in the last step.

Image gallery :


Connectors (Rear)
- 2x USB
- Center Cinch (blue)
- Sub Cinch (orange)
- Rückfahrkamera Cinch input (yellow)
- GPS aerial input
- DMB aerial input (not useable/included in Europe)
- microphone input
- Radio aerial input
Connectors ISO
- Green/Black : Rear Left Negative
- Green : Rear Left Positive
- White/Black : Front Left Negative
- White : Front Left Positive
- Purple/Black : Rear Right Negative
- Purple : Rear Right Positive
- Gray : Front Right Positive
- Gray/Black : Front Right Negative

- Light Green : Reverse Gear
- Orange/White : Illumination
- Pink : Attenuator
- Brown : Steering wheel control
- Blue : Antenna Turn On
- Light Blue : Hand Brake
- Blue/White : Amplifier Turn On
- Red : Ignition Plus
- Yellow : Power
- Black : GND/Minus
